Mechanical Vapor Recompression High Boiling Point Material Evaporation Technology

Main Advantages and Characteristics:

Material Characteristics: When the boiling point elevation of the material is higher than 18°C, a single-stage compressor is difficult to achieve evaporation, and the conventional MVR evaporation can no longer handle such materials.

Technical Characteristics: Our company has developed a multi-stage compressor series technology for materials with high boiling point elevation, achieving good application effects. The company's MVR evaporation technology for high boiling point elevation has realized stable operation with a liquid boiling point elevation of 35°C.

Customer Cases:

1.Inner Mongolia Chemical's 12-ton/hour dilute alkali concentration evaporation system

Material Characteristics: With the increase of concentration, the boiling point elevation is 19°C.

Energy Consumption per Ton of Treatment:Steam: 3 kg、Electricity: 44 kW、Circulating water: 7 tons

2.Qujing Battery Enterprise's 5-ton/hour manganese nitrate-iron evaporation and concentration system

Material Characteristics: With the increase of concentration, the boiling point elevation is 35°C.

Energy Consumption per Ton of Treatment: Steam: 3 kg、Electricity: 44KW、

Circulating water: 7 tons

 3.Ganzhou Battery Enterprise's 11.25-ton/hour ammonium chloride and ammonium sulfate evaporation system

Material Characteristics: With the increase of concentration, the boiling point elevation is 25°C.

Energy Consumption per Ton of Treatment:Steam: 3 kg、Electricity: 44 kW

Circulating water: 7 tons

4.Evaporation System for DTRO Concentrate of Landfill Leachate

8 sets of evaporation systems for DTRO concentrate of landfill leachate have been completed, such as Xu Zhou Yan Qun Landfill, Yang Zhou Zhao Zhuang Landfill, etc.

Energy Consumption per Ton of Treatment: Power consumption is approximately 60 kW·h per ton of water.
